Q-Switch Nd:YAG Laser (1064+532nm, 1000mj, 10hz ) Ruikd Genelux

Professional Q-Switch Nd:YAG laser with 1064 nm + 532 nm wavelengths, up to 1000 mJ energy and 10 Hz repetition rate.
Enquire now Download brochure
Q-Switch Nd:YAG Laser (1064+532nm, 1000mj, 10hz ) Ruikd Genelux
Technical Details

Q-Switch Nd:YAG Laser (1064+532nm, 1000mj, 10hz ) Ruikd Genelux Product Specifications

Display Type Digital LCD / Touchscreen Control Interface
Property Professional Q-Switched Nd:YAG system for tattoo/PMU removal, pigmentation treatment, carbon peeling, post-acne care and skin rejuvenation
Accuracy Adjustable spot size 1–5 mm; energy adjustable in 50 mJ increments at 1064 nm and 20 mJ increments at 532 nm; pulse width 12 ns
Power 500 W input power
Material Metal / ABS housing
Weight 22 kg
Frequency 1–10 Hz
Display Digital control interface / touchscreen configuration
Height 380 mm
Voltage 220–240 VAC
Dimension 610 × 450 × 380 mm
Phase Single Phase
Color Code White / Black
Handle ruikd-genelux-q-switch-nd-yag-laser
Vendor / Origin RUIKD · South Korea
Wavelength / Technology 1064 nm + 532 nm – Q-Switched Nd:YAG Laser Technology
Regulatory Line CE Certified & KFDA approved. Confirm CDSCO import registration with DermaSetup
Key Specifications
Q-Switched Nd:YAG laser; 1064 nm + 532 nm; maximum 1000 mJ at 1064 nm; 400 mJ at 532 nm; 1–10 Hz; 12 ns pulse width; water + air cooling; adjustable 1–5 mm spot size; multiple treatment handpieces
Q-Switch Nd:YAG Laser (1064+532nm, 1000mj, 10hz ) Ruikd Genelux

PRODUCT DETAILS

Advanced Dual-Wavelength Q-Switch Laser Technology


The Ruiked Genelux Q-Switch Nd:YAG Laser is a professional aesthetic laser system featuring dual wavelengths of 1064 nm and 532 nm. With maximum pulse energy up to 1000 mJ and a repetition rate of up to 10 Hz, the system is designed for a range of aesthetic applications, including tattoo removal, pigmentation treatments, carbon peel procedures and skin rejuvenation. Its Q-switched technology delivers high-intensity laser energy for precise and effective professional treatments.

ADVANCED TECHNOLOGY

Key Features

Advanced Q-Switch Nd:YAG laser system with dual wavelengths of 1064 nm and 532 nm, high pulse energy up to 1000 mJ and repetition rate up to 10 Hz. Designed for professional aesthetic treatments including tattoo removal, pigmentation treatment and skin rejuvenation.
01

Dual Wavelength 1064 nm + 532 nm

02

Q-Switched Technology

03

Maximum Energy 1000 mJ

Clinical applications

Treatments This Enables

01

Tattoo Removal, Pigmentation Treatment

02

Freckle Treatment, Sun Spot Treatment

03

Carbon Peel, Skin Brightening and Skin Rejuvenation

Expand Your Advanced Laser Treatment Services

Designed for clinic growth

Expand Your Advanced Laser Treatment Services

Expand your clinic's aesthetic treatment portfolio with a versatile dual-wavelength Q-Switch Nd:YAG laser. The system supports multiple professional applications, helping clinics offer tattoo removal, pigmentation treatments, carbon peel procedures and skin rejuvenation from one advanced platform.

01

Wider Handpiece Range

Interchangeable fractional and surgical-cutting handpiece options.

02

Multiple CO2 Procedures

Supports resurfacing, deeper scar revision and minor surgical cutting.

03

Clinic Growth

Useful for clinics expanding into more advanced CO2 procedures.
