Q-SWITCH LASER

ADSS Q-Switch Nd:YAG

Professional dual-wavelength Q-Switch Nd:YAG laser designed for pigmentation correction, tattoo removal, and carbon peel treatments with high-energy nanosecond pulse technology.
Enquire now Download brochure
ADSS Q-Switch Nd:YAG
Technical Details

ADSS Q-Switch Nd:YAG Product Specifications

Display Type Color Touchscreen LCD
Property Professional Q-Switched Nd:YAG Laser for Pigmentation & Tattoo Removal
Power 2000W
Material Metal / ABS Housing
Display Color Touchscreen
Voltage AC 220V / 50Hz or AC 110V / 60Hz
Phase Single Phase
Color Code White / Black
Handle adss-q-switch-nd-yag
Vendor / Origin ADSS · China
Wavelength / Technology Q-Switched Nd:YAG Laser – 1064 nm / 532 nm
Regulatory Line CE & FDA Certified.Confirm CDSCO import registration with DermaSetup
Key Specifications
High-energy Q-Switched Nd:YAG technology; dual wavelengths; adjustable spot size; short pulse duration; adjustable frequency; articulated laser delivery arm.
ADSS Q-Switch Nd:YAG

PRODUCT DETAILS

Product Overview

The ADSS Q-Switch Nd:YAG Laser is a high-performance dual-wavelength laser system engineered for professional pigment and tattoo treatment applications. It operates at 1064 nm and 532 nm, with output frequency adjustable from 1–10 Hz, pulse duration of approximately 5 ns, and an adjustable 2–10 mm spot size for controlled energy delivery across different treatment areas.

The system supports high-energy output, with up to 1600 mJ single-pulse energy at 1064 nm and up to 1000 mJ at 532 nm, depending on configuration. Its 7-articulated energy-delivery arm provides approximately 90% transmissibility for consistent laser delivery.

ADVANCED TECHNOLOGY

Key Features

Designed for modern dermatology and aesthetic clinics, the ADSS Q-Switch Nd:YAG combines dual-wavelength technology, high-energy nanosecond pulses, and adjustable spot sizing for pigmentation, tattoo removal, and carbon peel treatments.
01

1064 + 532nm Dual Wavelength

02

~5ns Pulse Width

03

Up to 1300mJ Energy

04

2600mJ Double-Pulse Mode

05

2–10mm Adjustable Spot Size

Clinical applications

Treatments This Enables

01

Pigmentation & Melasma

02

Tattoo Removal

03

Carbon Peel (Hollywood Facial)

Why This Matters for Your Clinic

Designed for clinic growth

Why This Matters for Your Clinic

Q-Switched Nd:YAG lasers deliver very short, high-energy nanosecond pulses that shatter pigment and tattoo ink into tiny fragments, allowing the body to naturally eliminate them. This technology provides a reliable and cost-effective solution for pigmentation correction and tattoo removal, making it an excellent entry point into advanced laser aesthetic treatments.

01

Wider Handpiece Range

Interchangeable fractional and surgical-cutting handpiece options.

02

Multiple CO2 Procedures

Supports resurfacing, deeper scar revision and minor surgical cutting.

03

Clinic Growth

Useful for clinics expanding into more advanced CO2 procedures.
